Test that viewer correctly handles the stroking of open and closed <path> elements
open
join=round
cap=butt
M, L
open
join=bevel
cap=round
m, l
open
join=miter
cap=square
M, L
closed
join=round
cap=butt
M, L, Z
closed
join=bevel
cap=round
m, l, z
closed
join=miter
cap=square
M, L, Z
$Revision: 1.13 $
|
|
|
Verify that the viewer renders the line caps and line joins for
open and closed paths properly.
Verify that the open triangular paths are stroked differently at
ends of the path than they are at their intermediate corners.
In contrast, the corners of a closed path should all appear the
same.
The rendered picture should match the reference image, except for possible
variations in the labelling text (per CSS2 rules).
