text-text-05-t
SVG Image PNG Image
text-fontSize-01-t.svg 1.x 1.y 4.x 1.y 2.x 1.y 1.x 4.y 4.x 4.y 2.x 4.y 1.x 2.y 4.x 2.y 2.x 2.y text-anchor start 1234 1234 1234 1234 1234 1234 1234 1234 1234 text-anchor middle text-anchor end $Revision: 1.8 $ raster image of text-text-05-t

The purpose of this test is to validate the interaction of text-anchor and x/y glyph positioning.

Each row shows a different combination of x/y values: 1, more than characters, fewer than characters. Each column shows different anchor values: start, middle and end.

The blue markers show the various x/y absolute positions around which text chunks should be anchored. The glyphs are black squares of increasing sizes.
